VTEC DT-DBC4R 4-Way Distributor Module
The VTEC DT-DBC4R 4-Way Distributor Module is designed for compatible VTEC 2-wire video intercom and door entry systems, particularly installations incorporating Wi-Fi-enabled indoor monitors.
Featuring four separate 2-wire BUS outputs, the DT-DBC4R allows the main intercom BUS to be distributed across four individual branches, providing a practical solution for connecting multiple indoor monitors within a structured system.
The DT-DBC4R is particularly important when installing compatible Wi-Fi-capable video intercom monitors, helping to provide the appropriate BUS distribution arrangement for reliable system operation.
The module features configurable impedance settings, integrated power and activity indicators, and convenient screw terminal connections. Its compact enclosed design makes it suitable for installation within residential and commercial intercom distribution systems.
Product Specifications
| Model | DT-DBC4R |
|---|---|
| Product Type | 4-Way Distributor / Branch Controller |
| System Compatibility | Compatible VTEC 2-Wire Systems |
| Wi-Fi Monitor Compatibility | Designed for Supported Wi-Fi Monitor Systems |
| Number of Branches | 4 x 2-Wire Branches |
| Output Connections | A / B / C / D |
| BUS Connections | 2-Wire BUS / Riser |
| Impedance Setting | Selectable ON / OFF |
| Status Indicators | Power / In-Use |
| Connections | Screw Terminal Connectors |
| Housing | Compact Plastic Enclosure |
Key Features
- Designed for compatible VTEC 2-wire systems
- Suitable for systems using Wi-Fi-enabled monitors
- Four independent 2-wire BUS branches
- Eight individual branch conductors
- Dedicated BUS and riser connections
- Configurable impedance switch
- Integrated power status indicator
- In-use activity indicator
- Convenient screw terminal connections
- Compact enclosed design
- Simplifies multi-monitor intercom installations
- Suitable for residential and commercial systems
Applications
The VTEC DT-DBC4R is suitable for apartment buildings, residential complexes, offices and multi-occupancy properties using compatible VTEC 2-wire video intercom equipment.
It is particularly recommended for installations incorporating Wi-Fi-capable indoor video monitors, where the appropriate distribution module is required to support the system's wiring configuration.
Important Installation Note
When installing compatible VTEC Wi-Fi-enabled indoor monitors, the DT-DBC4R distributor should be used where specified by the system installation requirements. Always refer to the relevant VTEC wiring diagrams and compatibility guidelines.
